Search function
To open the search panel use the command "search dlt logs".
(todo add picture)
The function searches for matching logs with the text in the payload text. See Search for ecu/apid/ctid on how to restrict/extend the search to ECU/APID/CTID.
Search modes
The search function has the following modes:
| mode name | description |
|---|---|
Use current document filter | The search will be limited to the logs matching the filters set in the current document. |
Use case sensitive | If set the search considers the case (upper/lower). If not set the search is case-insensitive. |
Use regular expression | If set the search text is a regular expression. E.g. ^error|^warning finds only logs starting with error or warning. If not set any logs containing the whole search text within the payload is found. E.g. err #2 matches all logs containing exactly err #2 in the payload. |
Search for ecu/apid/ctid
You can search for / restrict the search text to ECU/APID/CTID logs as well. This is similar to the DLT-Viewer "search header" option.
In general the syntax for ECU/APID/CTID is similar to adlt convert --eac cmd line option:
ECU:APID:CTID,ECU2:APID2:CTID2[,...]
Ecu, apid, ctid are separated by :. Empty ones are ignored. E.g. :apid: filters for apid only not for ecu. Entries can contain regex chars e.g.
ECU1|ECU2::
filters for ECU1 or ECU2.
Separate multiple filter by ,.
ECU/APID/CTID search in non regular expression mode
In normal / non regular expression search mode a ECU/APID/CTID search can be performed adding the following expression to the start of the search text.
The ECU/APID/CTID expression must be prepended with an @ and the normal search string needs to be separated with a space. E.g.
@ECU1 needle
searches for needle within all logs from ECU1.
The ECU/APID/CTID syntax is only evaluated if it's directly at the start of the search string after the @.
If you want dont want to search for ECU/APID/CTID but you first search word starts with @ add a space in front.
Examples:
| Search string | description |
|---|---|
@ECU1:APID needle | searches for needle in the payload text of all logs from ecu ECU1 with apid APID. |
@ needle | searches for @ needlein the payload text of all logs. (see the space at the front, which is not searched for) |
@ECU1::CTID,ECU2 error | searches for error in the payload text of all logs from ecu ECU1 with ctid CTID or from ecu ECU2. |
ECU/APID/CTID search in regular expression mode
In regular expression mode...
@ECU1 ^foo|@ECU2:API2 bar|error
searches for logs from ECU1 starting with foo or logs from ECU1:API2 containing bar or any log containing error
If the ECU/APID/CTID expression contains a regular expression with the \| symbol the whole expression needs to be put in round brackets! E.g. @(ECU1|ECU2) ....
Same logic applies as for non regular expression mode: if you want to search for a regex starting with @ prefix it with a space.
If you want to search for a regex starting with a space and a @ use \ @.
Examples:
| Search string | description |
|---|---|
@ECU1:APID needle|error | searches for logs from ECU1:APID containing needle or for any logs with error in the payload. |
@ECU1 (foo|bar) | searches for logs from ECU1 containing foo or bar |
@ECU1 foo|bar | searches for any logs containing @ECU1 foo or bar (see the space at the start) |
@ECU1 (foo|@ECU2 bar) | searches for logs from ECU1 containing for or @ECU2 bar (the @ECU2 is not an outer disjunction alternative!) |
@ECU1 foo|@ECU2 bar | searches for logs from ECU1 containing for or from ECU2 containing bar |
@:APID foo|@::CTID bar | searches for logs with apid APID containing for or with ctid CTID containing bar |
@(:AP1|AP2) foo|@::CTID (bar| @foo) | searches for logs with -- apid AP1 or apid AP2 containing for -- or with ctid CTID containing bar or @foo (space @foo).Take care: here the ECU/APID/CTID expression must be surrounded by brackets as it contains a |! |
@:APID | searches for all logs with apid APID |
@:APID,::CTID foo | searches for foo in all logs with apid APID or ctid CTID |
The search string is first parsed as a regular expression and for all disjunction alternatives (the parts splitted by |) it's checked whether a part starts with @ followed by a ECU/APID/CTID search syntax followed by a space. So the upper example is divided into:
@ECU1 ^foo
@ECU2:API2 bar
and
error
Those are transformed into 3 separate filters:
- ecu
ECU1, payloadRegex^foo - ecu
ECU2, apid:API2, payloadRegexbar - payloadRegex
error
